LQP100-DR1 100G Optical transceiver module are designed for use in 100 Gigabit Ethernet links over 500m single mode fiber. They are operating on 1311nm wavelength, compliant with the QSFP28 MSA. Digital diagnostics functions are available via the I2C interface, as specified by the QSFP28 MSA.
LQP100-FR1 100G Optical transceiver module are designed for use in 100 Gigabit Ethernet links over 2km single mode fiber. They are operating on 1311nm wavelength, compliant with the QSFP28 MSA. Digital diagnostics functions are available via the I2C interface, as specified by the QSFP28 MSA.
LQP100-LR1 100G Optical transceiver module are designed for use in 100 Gigabit Ethernet links over 10km single mode fiber. They are operating on 1311nm wavelength, compliant with the QSFP28 MSA. Digital diagnostics functions are available via the I2C interface, as specified by the QSFP28 MSA.
LQP100-ER1 100G Optical transceiver module are designed for use in 100 Gigabit Ethernet links over 40km single mode fiber. They are operating on 1311nm wavelength, compliant with the QSFP28 MSA. Digital diagnostics functions are available via the I2C interface, as specified by the QSFP28 MSA.
|
Part No. |
Description |
Data Rate |
Wavelength |
Distance |
Connector |
Download |
|
LQP100-DR1 |
QSFP28 DR |
1x100Gbps |
1311nm |
500m |
LC |
|
|
LQP100-FR1 |
QSFP28 FR |
1x100Gbps |
1311nm |
2KM |
LC |
|
|
LQP100-LR1 |
QSFP28 LR |
1x100Gbps |
1311nm |
10km |
LC |
|
|
LQP100-ER1 |
QSFP28 ER |
1x100Gbps |
1309.14nm |
40km |
LC |
- Operate on Single lambda 100G
- Supports 103 / 112Gbps aggregate bit rates
- Single 3.3V Power Supply and Industry Lowest Power dissipation
- Hot-Pluggable QSFP Footprint
- Class 1 FDA and IEC60825-1 Laser Safety Compliant
- RoHS Compliant
- Operating Case Temperature Standard: 0~+70℃
- Compliant with QSFP28 MSA Specification
- I2C interface with integrated Digital Diagnostic Monitoring
- 100GBASE-DR
- 100GBASE-FR
- 100GBASE-LR
- 100GBASE-ER
100G QSFP28 Single Lambda
